FreeCAD Tutorial
Export Drawing to PDF
- Create A3 page in the drawing module and set views.
- Goto
File > Export > PDF to to export.
How to make reinforcement:
These steps are to be performed in BIM workbench
- Create BIM structure and select its face.
- Open Reinforcement tool, select reinforcement type. Enter its properties.
- Pick the selected face and press apply, then ok. Change the transperency of BIM Object to View > Transperency to 35% to see the reinforcement inside.
